Completely Front Maintenance
Redundant Power Supply & Signal Backup IP65 Level Rear Protection & Clean Routing
Ultra-thin Mounting
Wireless Connection
| Item | T300 | TY300 | TYF300 |
|---|---|---|---|
| Module Size（mm*mm） | 150*56.25 | ||
| Module Resolution（L*W) | 120*45 | ||
| Scanning mode | 11/45 | ||
| LED Configuration | COB 1R1G1B | ||
| Control Way | Synchronous | Asynchronous | Sync./Async.(Option) |
| Installation Way | Hanging/ mounted | ||
| Cabinet Size（mm*mm） | 300*60*23 | ||
| Cabinet Resolution（L*W) | 240*45 | ||
| Physical Density（dot/m²） | 640000 | ||
| Brightness（cd/m²） | 50~600cd/m² adjustable | ||
| Cabinet Max Power Consumption | 15W | ||
| Cabinet Aver. Power Consumption | 5W | ||
| Cabinet Weight（KG) | 0.35kg | ||
| Cabinet Material | Profile aluminum | ||
| Protection Level | Pixel face IP65 | ||
| Contrast Ratio | 10000:1 | ||
| Grey Scale | 14bit | ||
| Refresh Rate（Hz） | 3840Hz | ||
| Refresh Frame Frequency（Hz） | 50Hz/60Hz | ||
| Horizontal View Angle（Deg） | ≥170° | ||
| Vertical View Angle（Deg） | ≥170° | ||
| Best Viewing Distance（M） | 1.3M | ||
| Input signal | RJ45 | ||
| Max Length | 4.8M | ||
| Input Voltage（V） | 24V | ||
| Module Max Current（A) | 0.6A | ||
| Working Temperature（℃） | -20℃+80℃ | ||
| Working Humility（RH） | 10％RH~95％RH | ||
| Life Span（H) | ≥100000 | ||
| MTBF（H) | ≥10000 | ||
