Cabinet Size：customized
Pixel Pitch：P2.5/3/4.8/4/5/6/8/10
Drive Mode：Common Anode
Service Way：Front Service
LED lamp：SMD
Brightness：3000~6500CD/m²
| Item | AH3 | AH3.8 | AH6 | AH2.5 | AH4 | AH5 | AH8 | AH10 |
|---|---|---|---|---|---|---|---|---|
| Pixel Pitch (mm) | 3.0 | 3.8 | 6.0 | 2.5 | 4.0 | 5.0 | 8.0 | 10 |
| Module Size（mm*mm） | 192*192*18 | 320*160*21 | ||||||
| Module Resolution（L*W) | 64*64 | 50*50 | 32*32 | 128*64 | 80*40 | 64*32 | 40*20 | 32*16 |
| Scanning mode | 1/16 | 1/13 | 1/4 | 1/16 | 1/10 | 1/8 | 1/3 | 1/2 |
| LED Configuration | 1R1G1B | |||||||
| LED Type | 1415/1921 | 1921 | 2727 | 1415 | 1921 | 2727 | 3535 | 3535 |
| Service Way | Back Service | |||||||
| Installation Way | Back Installation | |||||||
| Cabinet Size（mm*mm） | Customized | |||||||
| Cabinet Resolution（L*W) | 192*192 | 150*150 | 96*96 | 256*192 | 240*240 | 192*192 | 120*120 | 96*96 |
| Physical Density（dot/m²） | 111111 | 67816 | 27777 | 160000 | 62500 | 40000 | 15625 | 10000 |
| Brightness（cd/m²） | 6000~6500 | 6000~6500 | 6000~7000 | 6000~6500 | 6000~6500 | 6000~7000 | 6000~7000 | 6000~7000 |
| Cabinet Max Power Consumption | 800W | |||||||
| Cabinet Aver. Power Consumption | 260W | |||||||
| Cabinet Weight（KG) | 11kg | 30kg | ||||||
| Cabinet Material | Aluminum Magnesium (iron/aluminum option) | |||||||
| Protection Level | Face IP65 | |||||||
| Contrast Ratio | ≥5000:1 | |||||||
| Grey Scale | 14bit | |||||||
| Refresh Rate（Hz） | 1920/3840Hz | |||||||
| Refresh Frame Frequency（Hz） | 50Hz-60Hz | |||||||
| Horizontal View Angle（Deg） | ≥140° | |||||||
| Vertical View Angle（Deg） | ≥120° | |||||||
| Best Viewing Distance（M） | 3M | 4M | 6M | 2.5M | 4M | 5M | 8M | 10M |
| Input Voltage（V） | AC110Vz~AC220V | |||||||
| Module Max Current（A) | 6.5A | 6A | 6A | 8.5A | 8A | 8A | 8.5A | 8.5A |
| Working Temperature（℃） | -20℃+80℃ | |||||||
| Working Humility（RH） | 10％RH~95％RH | |||||||
| Life Span（H) | ≥100000 | |||||||
| MTBF（H) | ≥10000 | |||||||
